BIOPAC ECG100C

The BIOPAC ECG100C device is an add-on to the MP160 and MP150 devices and records electrical activity generated by the heart. Recording ECG data from various locations allows researchers to study the properties of the ECG wave and implement a fully automated analysis.

Specifications

Model	BIOPAC ECG100C
Gain	500, 1000, 2000, 5000
Output range	±10 V (analog)
Frequency response	Low Pass Filter: 35 Hz, 150 Hz, High Pass Filter: 0.05 Hz, 1.0 Hz
Notch filter	50 dB rejection @ 50 Hz or 60 Hz
Noise voltage	0.1 µV rms – (0.05-35 Hz)
Signal source	Electrodes (three electrode leads required)
Weight	350 g
Dimensions	4 x 11 x 19 cm
Input connectors	Five 1.5 mm male Touchproof sockets (Vin+, Ground, Vin-, 2 of shield)
